Heavy Duty/Commercial Specifications
| MODEL | Voltage | PHCA** (5 sec.) |
CCA* | HCA | MCA | Nominal Capacity | Reserve Capacity Minutes |
Length inches (mm) |
Width inches (mm) |
Height inches (mm) |
Weight lbs (kg) |
Terminal | Torque Specs in-lbs (Nm max) |
Internal Resistance (mΩ) |
Short Circuit Current |
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (20 Hr Rate-Ah) |
(10 Hr Rate-Ah) |
|||||||||||||||
 75-PC1230 |
12 | 1230 | 730 | 1050 | 815 | 55 | 50 | 100 | 9.46 (240.3) |
6.99 (177.5) |
7.22 (201.2) |
45.5 (20.6) |
TOP SAE SIDE 3/8" Receptacle |
60 (6.8) |
2.5 | 3100A |
 75/86-PC1230 |
12 | 1230 | 730 | 1050 | 815 | 55 | 50 | 100 | 9.46 (240.3) |
6.99 (177.5) |
7.22 (201.2) |
45.5 (20.6) |
Side 3/8" Receptacle |
60 (6.8) |
2.5 | 3100A |
 25-PC1400 |
12 | 1400 | 820 | 1150 | 850 | 60 | 55 | 125 | 9.46 (240.3) |
6.84 (173.7) |
8.69 (220.7) |
50.0 (22.7) |
SAE | 70 (7.9) |
2.5 | 3100A |
 35-PC1400 |
12 | 1400 | 820 | 1150 | 850 | 65 | 55 | 125 | 9.46 (240.3) |
6.84 (173.7) |
8.69 (220.7) |
50.0 (22.7) |
SAE | 70 (7.9) |
2.5 | 3100A |
 34-PC1500 |
12 | 1500 | 880 | 1250 | 1050 | 68 | 62 | 135 | 10.85 (275.6) |
6.76 (171.7) |
7.82 (198.6) |
49.5 (22.4) |
SAE | 60 (6.8) |
2.5 | 3100A |
 34R-PC1500 |
12 | 1500 | 880 | 1250 | 1050 | 68 | 62 | 135 | 10.85 (275.6) |
6.76 (171.7) |
7.82 (198.6) |
49.5 (22.4) |
SAE | 60 (6.8) |
2.5 | 3100A |
 34/78-PC1500 |
12 | 1500 | 880 | 1250 | 1050 | 68 | 62 | 135 | 10.85 (275.6) |
6.99 (177.5) |
7.82 (198.6) |
49.5 (22.4) |
TOP SAE SIDE 3/8" Receptacle |
60 (6.8) |
2.5 | 3100A |
78-PC1500 |
12 | 1500 | 880 | 1250 | 1050 | 68 | 62 | 135 | 10.85 (275.6) |
6.99 (177.5) |
7.12 (198.6) |
49.5 (22.4) |
Side 3/8" Receptacle |
60 (6.8) |
2.5 | 3100A |
 65-PC1750 |
12 | 1750 | 930 | 1350 | 1070 | 74 | 65 | 135 | 11.83 (300.5) |
7.20 (182.9) |
7.43 (188.7) |
58.0 (26.3) |
SAE | 70 (7.9) |
2.0 | 5000A |
 31-PC2150 |
12 | 2150 | 1150 | 1545 | 1370 | 100 | 92 | 205 | 13.00 (330.2) |
6.80 (172.7) |
9.41 (239.0) |
77.8 (35.3) |
3/8" Stud or SAE |
150-200 (16.9-22.6) |
2.2 | 5000A |
 PC2250 |
12 | 2250 | 1225 | 1730 | 1550 | 126 | 114 | 240 | 11.26 (286.0) |
10.59 (269.0) |
9.17 (233.0) |
86.0 (39.0) |
DIN | 100 (11.0) for 3/8" Stud Only |
2.1 | 5000A |
*Cold Start Performance S.A.E J537 JUNE 82 |
Constant voltage portable charger parameters: |
|
| Standby, per 12V battery | 13.5-13.8V no current limit required | |
| Cyclic, per 12V battery (16-hour recharge) | 14.4-14.8V no current limit required | |
| Typical deep-cycle life at 25°C/77°F at a 5-hour rate |
400 cycles at 80% DOD | |
| Typical service life at 25°C/77°F | Medium to heavy duty usage – 3+ years Light duty usage – 5+ years |
|
Optional height adapter
Optional height adapter may be used on both 34-PC1500 models for installations where a group 24 or group 27 is required. Snap the adapter securely into place on the bottom of the 34-PC1500 battery. In some installations, either 34-PC1500 model with this adapter may be used to replace a group 24F or 27F depending on required cable length.
